ASTM A106 Grade C material specification properties
ASTM A106 Grade C introduction
ASTM A106 is a set of standard specifications developed by the American Society for Testing and Materials (ASTM) for the use of seamless carbon steel pipe in high-temperature service. The standard covers two types of seamless carbon steel pipes:
- Class A: Suitable for applications with a maximum operating temperature of 454°C.
- Class B: Suitable for applications with a maximum operating temperature of 565°C.
ASTM A106 Grade C seamless steel pipe is widely used in various industries such as petroleum, chemical industry, boilers, power stations, ships, machinery manufacturing, automobiles, aviation, aerospace, energy, geology, construction and military industry.
ASTM A106 Grade C General properties
The General properties requirements of ASTM A106 Grade C are as follows:
| Property | Temperature | Value |
|---|---|---|
| Elongation A50 | 23.0 °C | Elongation A50 of 16.5 - 30 % |
| Tensile strength | 23.0 °C | Tensile strength of 485 MPa |
| Yield strength | 23.0 °C | Yield strength of 275 MPa |
ASTM A106 Grade C Chemical composition
The Chemical composition requirements of ASTM A106 Grade C are as follows:
| Property | Value |
|---|---|
| Carbon | Carbon of 0.35 % |
| Chromium | Chromium of 0.4 % |
| Copper | Copper of 0.4 % |
| Manganese | Manganese of 0.29 - 1.06 % |
| Molybdenum | Molybdenum of 0.15 % |
| Nickel | Nickel of 0.4 % |
| Phosphorus | Phosphorus of 0.04 % |
| Silicon | Silicon of 0.1 % |
| Sulfur | Sulfur of 0.035 % |
| Vanadium | Vanadium of 0.08 % |
